LGC 200 uses the absorption characteristics of methane gas for a certain wavelength laser, adopts tunable semiconductor laser spectral absorption technology (TDLAS)
oem/odm
STEL and TWA monitoring; Atmosphere monitoring; Monitoring for cleanliness of environment; Petroleum and chemical plant; Entering of sealing space; Quick respond for dangerous substance/ chemical weapon; Industrial paints; Leakage detecting; IAQ monitoring of indoor air quality; Soil pollution monitoring.
LGC 200 uses the absorption characteristics of methane gas for a certain wavelength laser, adopts tunable semiconductor laser spectral absorption technology (TDLAS), and uses the good monochromy and modulability characteristics of semiconductor laser to realize the analysis and detection of methane gas absorption spectral line.
♦ Metal body, intelligent detection, stable performance, no error report
♦ Response speed is 0.05S, suitable for dynamic detection
♦ Industrial design, waterproof, dustproof, anti-fall
♦ Excellent man-machine functional design for stable detection
| Model | LGC 200 |
| Gas Detection | Methane(CH4) |
| Detecting distance | ≥150m |
| Detection range | 0-99999ppm.m |
| Static detection limit | 5ppm.m |
| Response time | 0.05s |
| Resolution | 1ppm.m |
| Safety level of Laser | Class 1 |
| Working temperature | -20-50℃ |
| Storage temperature | -40-60℃ |
| Working humidity | 0-95%RH（No condensing） |
| Battery capacity | 6000mAh |
| Standby of battery | ≥8h |
| Weight | ≤700g |
| Ex marks | ExibIICT4Gb |
| Ingress protection | IP67 |
Oil and Gas drilling
Metallurgy
Mining industry
Power Plant
Steel plant
Gas pipeline project
